General Specs |
| Product Weight (lbs.) | 81 |
| Depth Excluding Handles (in.) | 23.5 |
| Depth Including Handles (in.) | 23.5 |
| Steam | No |
| Depth w/Door Open 90 Degrees (in.) | 46.5 |
| ENERGY STAR Certified | Yes |
| Food Disposal | Yes |
| Number of Cycles | 3 |
| Appliance Color | Stainless Steel |
| Cutlery Holder | No |
| Delay Wash (Up to hours) | 12 |
| Depth (in.) | 23.5 |
| Handle Type | Recessed |
| Height (in.) | 32.25 |
| Interior (Settings) | 12 |
| Noise level (dB) | 51 |
| Stemware Holder | No |
| Tub Material | Stainless Steel |
| Width (in.) | 23.75 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Appliance Fit Width (in.) | 24 |
| Custom Panel Ready | No |
| Sanitize Option | Yes |
| Smart Compatible | No |
| Color Finish Name | Stainless Steel |
| Steam Option | No |
| Number Of Place Settings | 12 |
| ADA Compliant | Yes |
| Voice Activated | No |
| Bluetooth Capable | No |
| Child Lock | Yes |
| Cut Out Width | 23.75 |
| Cut Out Height | 32.25 |
| Fingerprint Resistant Finish | No |
| Sensor Wash | Yes |
| Dishwasher Type | Built-In |
| Control Panel Type | Top |
| Cut Out Depth | 24 |
| Voltage | 120 |
| Frequency | 60 |
| Amp | 8.9 |
| Sound Rating Range | Quiet |
| Third Rack | No |
Features |
| Control Type | 4 Pushbuttons; Fully Integrated Electronic; Top Controls |
| Dishwasher Control Features | 3 Digit Countdown Display with 1 "Clean" light / 1 "Sanitized" light Cycle Progress Indicators; Audible End-of-Cycle Signal; Cycle Countdown; Last Cycle Memory; Start/Reset Pad |
| Wash System | 3-Level; Standard |
| Wash System Features | Automatic HotStart; Automatic Temperature Control; Dual Pump; Flood Control System; Piranha™ Hard Food Disposer |
| Sensor | Clean Sensor |
| Wash Arms | 2 with Upper Nozzle |
| Water Filtration System | 3-Stage Manual Clean Filtration |
| Dispenser | Rinse Aid with Indicator and Adjustment |
| Dishwasher Cycles | Auto Sense; Heavy Wash; Light Wash |
| Number of Options | 5 |
| Dishwasher Options | Child Lock; Delay Start 1-12 Hr.; Sani (NSF Certified); Start/Reset; TempBoost |
| Rack Features | 1 Plastic Utility Shelf - Upper; 2 Piece Silverware Basket with Cell Covers; Ball-Tipped Tines; Stem Safe |
| Racking System | Gray |
| Upper Rack | Adjustable |
| Nylon | Nylon |
| Lower Rack | Nylon |
| Dishwasher Drying Features | Condensate Dry |
| Leveling System | Leveling Legs |
| Latch | Center Pull |
| WiFi Connect | Optional (Requires part no. PBX10W00Y0) |
| Connected Capabilities | Amazon Alexa; IFTTT; The Google Assistant |
Appearance |
| Door Style | Stainless Full-Length Flat Door |
| Handle | Towel Bar |
| Handle Color | Color-Matched |
| Handle Design | Recessed |
Economical / Quiet |
| Quiet Features | Sealed Toe Kick; Tub Collar Trim |
| Motor Type | Single Speed |
| Outer Wrap | U-Blanket |
| Door Insulation | Insulation; Mastic |
Weights & Dimensions |
| Cabinet Width | 24 in |
| Approximate Shipping Weight | 96 lb |
| Height w/ Legs Retracted - Minimum Height | 32.25 in |
| Height w/Legs Extended - Maximum Height | 34.63 in |
Power / Ratings |
| Calrod Heater Watts | 1100 |
Energy Guide |
| kWh | 270 |
